TL494C, TL494I, TL494M, TL494Y PULSE-WIDTH-MODULATION CONTROL CIRCUITS SLVS074A - JANUARY 1983 - REVISED AUGUST 1995 * * * * * Complete PWM Power Control Circuitry TL494C, TL494I . . . D, N, OR PW PACKAGE TL494M . . . J PACKAGE (TOP VIEW) Uncommitted Outputs for 200-mA Sink or Source Current Output Control Selects Single-Ended or Push-Pull Operation 1IN + 1 16 2IN + 1IN - 2 15 2IN - FEEDBACK 3 14 REF DTC 4 13 OUTPUT CTRL CT 5 12 RT 6 11 VCC C2 GND 7 10 E2 C1 8 9 E1 Internal Circuitry Prohibits Double Pulse at Either Output Variable Dead Time Provides Control Over Total Range Internal Regulator Provides a Stable 5-V Reference Supply With 5% Tolerance TL494M . . . FK PACKAGE Circuit Architecture Allows Easy Synchronization (TOP VIEW) 1IN- 1IN+ NC 2IN+ 2IN- * * description FEEDBACK DTC NC CT RT The TL494 contains two error amplifiers, an on-chip adjustable oscillator, a dead-time control (DTC) com

TL494 PULSE-WIDTH-MODULATION CONTROL CIRCUITS www.ti.com SLVS074E - JANUARY 1983 - REVISED FEBRUARY 2005 FEATURES * * * * * * * D, DB, N, NS, OR PW PACKAGE (TOP VIEW) Complete PWM Power-Control Circuitry Uncommitted Outputs for 200-mA Sink or Source Current Output Control Selects Single-Ended or Push-Pull Operation Internal Circuitry Prohibits Double Pulse at Either Output Variable Dead Time Provides Control Over Total Range Internal Regulator Provides a Stable 5-V Reference Supply With 5% Tolerance Circuit Architecture Allows Easy Synchronization 1IN+ 1IN- FEEDBACK DTC CT RT GND C1 1 16 2 15 3 14 4 13 5 12 6 7 10 8 9 11 2IN+ 2IN- REF OUTPUT CTRL VCC C2 E2 E1 DESCRIPTION The TL494 incorporates all the functions required in the construction of a pulse-width-modulation (PWM) control circuit on a single chip. Designed primarily for power-supply control, this device offers the flexibility to tailor the power-supply control circuitry to a specific application. The TL494 conta

TL494 PULSE-WIDTH-MODULATION CONTROL CIRCUITS www.ti.com SLVS074E - JANUARY 1983 - REVISED FEBRUARY 2005 FEATURES * * * * * * * D, DB, N, NS, OR PW PACKAGE (TOP VIEW) Complete PWM Power-Control Circuitry Uncommitted Outputs for 200-mA Sink or Source Current Output Control Selects Single-Ended or Push-Pull Operation Internal Circuitry Prohibits Double Pulse at Either Output Variable Dead Time Provides Control Over Total Range Internal Regulator Provides a Stable 5-V Reference Supply With 5% Tolerance Circuit Architecture Allows Easy Synchronization 1IN+ 1IN- FEEDBACK DTC CT RT GND C1 1 16 2 15 3 14 4 13 5 12 6 7 10 8 9 11 2IN+ 2IN- REF OUTPUT CTRL VCC C2 E2 E1 DESCRIPTION The TL494 incorporates all the functions required in the construction of a pulse-width-modulation (PWM) control circuit on a single chip. Designed primarily for power-supply control, this device offers the flexibility to tailor the power-supply control circuitry to a specific application. The TL494 conta

TL494 PULSE-WIDTH-MODULATION CONTROL CIRCUITS www.ti.com SLVS074E - JANUARY 1983 - REVISED FEBRUARY 2005 FEATURES * * * * * * * D, DB, N, NS, OR PW PACKAGE (TOP VIEW) Complete PWM Power-Control Circuitry Uncommitted Outputs for 200-mA Sink or Source Current Output Control Selects Single-Ended or Push-Pull Operation Internal Circuitry Prohibits Double Pulse at Either Output Variable Dead Time Provides Control Over Total Range Internal Regulator Provides a Stable 5-V Reference Supply With 5% Tolerance Circuit Architecture Allows Easy Synchronization 1IN+ 1IN- FEEDBACK DTC CT RT GND C1 1 16 2 15 3 14 4 13 5 12 6 7 10 8 9 11 2IN+ 2IN- REF OUTPUT CTRL VCC C2 E2 E1 DESCRIPTION The TL494 incorporates all the functions required in the construction of a pulse-width-modulation (PWM) control circuit on a single chip. Designed primarily for power-supply control, this device offers the flexibility to tailor the power-supply control circuitry to a specific application. The TL494 conta
