MBR2545CT-1 SCHOTTKY RECTIFIER 30 Amp Description/Features Major Ratings and Characteristics Characteristics This center tap Schottky rectifier has been optimized for low reverse leakage at high temperature. The proprietary barrier technology allows for reliable operation up to 150 C junction temperature. Typical applications are in switching power supplies, converters, free-wheeling diodes, and reverse battery protection. Values Units 30 A 30 A 150 C TJ operation Center tap TO-220 and D2Pak packages VRRM 35/45 V IFSM @ tp = 5 s sine 1060 A Low forward voltage drop High purity, high temperature epoxy encapsulation for enhanced mechanical strength and moisture resistance High frequency operation VF @ 30 Apk, TJ = 125C 0.73 V TJ range - 65 to 150 C IF(AV) Rectangular waveform (Per Device) IFRM @ TC = 130C (Per Leg) Guard ring for enhanced ruggedness and long term reliability Case Styles MBR2535CT MBR2545CT MBRB2535CT MBRB2545CT MBR2535CT-1 MBR2545CT-1 TO-220 D2PAK TO-262 www.irf.com 1

MBR2545CT-1 SCHOTTKY RECTIFIER 30 Amp Description/Features Major Ratings and Characteristics Characteristics This center tap Schottky rectifier has been optimized for low reverse leakage at high temperature. The proprietary barrier technology allows for reliable operation up to 150 C junction temperature. Typical applications are in switching power supplies, converters, free-wheeling diodes, and reverse battery protection. Values Units 30 A 30 A 150 C TJ operation Center tap TO-220 and D2Pak packages VRRM 35/45 V IFSM @ tp = 5 s sine 1060 A Low forward voltage drop High purity, high temperature epoxy encapsulation for enhanced mechanical strength and moisture resistance High frequency operation VF @ 30 Apk, TJ = 125C 0.73 V TJ range - 65 to 150 C IF(AV) Rectangular waveform (Per Device) IFRM @ TC = 130C (Per Leg) Guard ring for enhanced ruggedness and long term reliability Case Styles MBR2535CT MBR2545CT MBRB2535CT MBRB2545CT MBR2535CT-1 MBR2545CT-1 TO-220 D2PAK TO-262 www.irf.com 1

MBR2545CT-1 SCHOTTKY RECTIFIER 30 Amp Major Ratings and Characteristics Characteristics Description/ Features This center tap Schottky rectifier has been optimized for low reverse leakage at high temperature. The proprietary barrier technology allows for reliable operation up to 150 C junction temperature. Typical applications are in switching power supplies, converters, free-wheeling diodes, and reverse battery protection. Values Units 30 A 30 A VRRM 35/45 V Center tap TO-220 and D2Pak packages Low forward voltage drop IFSM @ tp = 5 s sine 1060 A High purity, high temperature epoxy encapsulation for enhanced mechanical strength and moisture resistance VF @ 30 Apk, TJ = 125C 0.73 V TJ range - 65 to 150 C IF(AV) Rectangular waveform (Per Device) IFRM @ TC = 130C (Per Leg) 150 C TJ operation High frequency operation Guard ring for enhanced ruggedness and long term reliability Case Styles MBR25..CT MBRB25.. CT Base Common Cathode Base Common Cathode 2 1 Anode 2 Common Cathode TO-220 www.irf.com MBR2

RM IFSM tp = 5 s sine VF 30 Apk, TJ = 125 C TJ Range UNITS A 35/45 V 1060 A 0.73 V -65 to 150 C VOLTAGE RATINGS PARAMETER Maximum DC reverse voltage Maximum working peak reverse voltage SYMBOL VR VRWM VS-MBRB2535CT-M3 VS-MBR2535CT-1-M3 VS-MBRB2545CT-M3 VS-MBR2545CT-1-M3 UNITS 35 45 V Revision: 03-Mar-14 Document Number: 94952 1 For technical questions within your region: DiodesAmericas@vishay.com, DiodesAsia@vishay.com, DiodesEurope@vishay.com THIS DOCUMENT IS SUBJECT TO CHANGE WITHOUT NOTICE. THE PRODUCTS DESCRIBED HEREIN AND THIS DOCUMENT ARE SUBJECT TO SPECIFIC DISCLAIMERS, SET FORTH AT www.vishay.com/doc?91000 VS-MBRB25..CT-M3, VS-MBR25..CT-M3 www.vishay.com Vishay Semiconductors ABSOLUTE MAXIMUM RATINGS PARAMETER Maximum average forward current SYMBOL per leg per device Peak repetitive forward current per leg Non-repetitive peak surge current TC = 130 C, rated VR IFRM Rated VR, square wave, 20 kHz, TC = 130 C 5 s sine or 3 s rect. pulse VALUES UNITS 15 IF(AV) IFSM Non-repetitive avalanche en

M IFSM tp = 5 s sine VF 30 Apk, TJ = 125 C TJ Range UNITS A 35/45 V 1060 A 0.73 V - 65 to 150 C VOLTAGE RATINGS PARAMETER SYMBOL Maximum DC reverse voltage VR Maximum working peak reverse voltage VRWM VS-MBRB2535CTPbF VS-MBR2535CT-1PbF VS-MBRB2545CTPbF VS-MBR2545CT-1PbF UNITS 35 45 V ABSOLUTE MAXIMUM RATINGS PARAMETER Maximum average forward current SYMBOL per leg per device Peak repetitive forward current per leg Non-repetitive peak surge current TEST CONDITIONS TC = 130 C, rated VR IFRM Rated VR, square wave, 20 kHz, TC = 130 C IFSM UNITS 15 IF(AV) 5 s sine or 3 s rect. pulse VALUES 30 Following any rated load condition and with rated VRRM applied 30 1060 Surge applied at rated load conditions halfwave, single phase, 60 Hz 150 A Non-repetitive avalanche energy per leg EAS TJ = 25 C, IAS = 2 A, L = 8 mH 16 mJ Repetitive avalanche current per leg IAR Current decaying linearly to zero in 1 s Frequency limited by TJ maximum VA = 1.5 x VR typical 2 A Document Number: 94308 Revision: 16-Mar-10 For te

2 Common Cathode 3 Anode TO-262 1 MBR25..CT, MBRB25..CT, MBR25..CT-1 Bulletin PD-2.322 rev. E 01/07 Voltage Ratings Parameters VR Max. DC Reverse Voltage (V) V RWM Max. Working Peak Reverse Voltage (V) MBR2535CT MBRB2535CT MBR2535CT-1 MBR2545CT MBRB2545CT MBR2545CT-1 35 45 Absolute Maximum Ratings Parameters Values Units 15 30 30 A @ TC = 130 C, (Rated VR) A Rated V R, square wave, 20kHz T C = 130 C IF(AV) Max. Average Forward (Per Leg) Current (Per Device) IFRM Peak Repetitive Forward Current (Per Leg) IFSM Non Repetitive Peak Surge Current 1060 A 150 EAS Non-Repetitive Avalanche Energy IAR Repetitive Avalanche Current (Per Leg) 16 mJ 2 A Values Units Conditions 5s Sine or 3s Following any rated load condition and with rated V RRM applied Rect. pulse Surge applied at rated load conditions halfwave, single phase, 60Hz (Per Leg) T J = 25 C, IAS = 2 Amps, L = 8 mH Current decaying linearly to zero in 1 sec Frequency limited by TJ max. VA = 1.5 x VR typical Electrical Specifications Parameters VFM I

se Common Cathode 2 1 Anode 2 Common Cathode D2PAK www.irf.com 2 3 Anode 1 Anode 2 Common Cathode 3 Anode TO-262 1 MBRB25..CTPbF, MBR25..CT-1PbF Series Bulletin PD-21045 rev. A 07/06 Voltage Ratings Parameters VR MBRB2535CTPbF MBR2535CT-1PbF MBRB2545CTPbF MBR2545CT-1PbF 35 45 Max. DC Reverse Voltage (V) VRWM Max. Working Peak Reverse Voltage (V) Absolute Maximum Ratings Parameters IF(AV) Max. Average Forward (Per Leg) Current (Per Device) IFRM Peak Repetitive Forward Current (Per Leg) IFSM Non Repetitive Peak Surge Current Values Units 15 30 30 A @ TC = 130 C, (Rated VR) A Rated VR, square wave, 20kHz TC = 130 C 1060 A 150 EAS Non-Repetitive Avalanche Energy 16 mJ IAR Repetitive Avalanche Current 2 A (Per Leg) Conditions 5s Sine or 3s Following any rated load condition and with rated V RRM applied Rect. pulse Surge applied at rated load conditions halfwave, single phase, 60Hz (Per Leg) TJ = 25 C, IAS = 2 Amps, L = 8 mH Current decaying linearly to zero in 1 sec Frequency limited by TJ max. VA = 1

ERISTICS SYMBOL CHARACTERISTICS VALUES IF(AV) Rectangular waveform (per device) 30 IFRM TC = 130 C (per leg) 30 VRRM IFSM tp = 5 s sine VF 30 Apk, TJ = 125 C TJ Range UNITS A 35/45 V 1060 A 0.73 V - 65 to 150 C MBRB2535CTPbF, MBR2535CT-1PbF MBRB2545CTPbF, MBR2545CT-1PbF UNITS 35 45 V VOLTAGE RATINGS PARAMETER SYMBOL Maximum DC reverse voltage VR Maximum working peak reverse voltage VRWM ABSOLUTE MAXIMUM RATINGS PARAMETER Maximum average forward current SYMBOL per leg per device Peak repetitive forward current per leg TEST CONDITIONS Non-repetitive peak surge current Non-repetitive avalanche energy per leg Repetitive avalanche current per leg 15 IF(AV) TC = 130 C, rated VR IFRM Rated VR, square wave, 20 kHz, TC = 130 C 5 s sine or 3 s rect. pulse IFSM VALUES UNITS 30 Following any rated load condition and with rated VRRM applied 30 1060 A Surge applied at rated load conditions halfwave, single phase, 60 Hz 150 EAS TJ = 25 C, IAS = 2 A, L = 8 mH 16 mJ IAR Current decaying linearly to zero in 1 s Fr

AND CHARACTERISTICS SYMBOL CHARACTERISTICS VALUES IF(AV) Rectangular waveform (per device) 30 IFRM TC = 130 C (per leg) 30 VRRM UNITS A 35/45 V IFSM tp = 5 s sine 1060 A VF 30 Apk, TJ = 125 C 0.73 V TJ Range - 65 to 150 C MBRB2535CT MBR2535CT-1 MBRB2545CT MBR2545CT-1 UNITS 35 45 V VOLTAGE RATINGS PARAMETER SYMBOL Maximum DC reverse voltage VR Maximum working peak reverse voltage VRWM ABSOLUTE MAXIMUM RATINGS PARAMETER Maximum average forward current SYMBOL per leg per device Peak repetitive forward current per leg TEST CONDITIONS Non-repetitive peak surge current Non-repetitive avalanche energy per leg Repetitive avalanche current per leg Document Number: 93979 Revision: 21-Aug-08 15 IF(AV) TC = 130 C, rated VR IFRM Rated VR, square wave, 20 kHz, TC = 130 C 5 s sine or 3 s rect. pulse IFSM VALUES UNITS 30 Following any rated load condition and with rated VRRM applied 30 1060 A Surge applied at rated load conditions halfwave, single phase, 60 Hz 150 EAS TJ = 25 C, IAS = 2 A, L = 8 mH 16 mJ IAR Cur

M IFSM tp = 5 s sine VF 30 Apk, TJ = 125 C TJ Range UNITS A 35/45 V 1060 A 0.73 V - 65 to 150 C VOLTAGE RATINGS PARAMETER SYMBOL Maximum DC reverse voltage VR Maximum working peak reverse voltage VRWM VS-MBRB2535CTPbF VS-MBR2535CT-1PbF VS-MBRB2545CTPbF VS-MBR2545CT-1PbF UNITS 35 45 V ABSOLUTE MAXIMUM RATINGS PARAMETER Maximum average forward current SYMBOL per leg per device Peak repetitive forward current per leg Non-repetitive peak surge current TEST CONDITIONS TC = 130 C, rated VR IFRM Rated VR, square wave, 20 kHz, TC = 130 C IFSM UNITS 15 IF(AV) 5 s sine or 3 s rect. pulse VALUES 30 Following any rated load condition and with rated VRRM applied 30 1060 Surge applied at rated load conditions halfwave, single phase, 60 Hz 150 A Non-repetitive avalanche energy per leg EAS TJ = 25 C, IAS = 2 A, L = 8 mH 16 mJ Repetitive avalanche current per leg IAR Current decaying linearly to zero in 1 s Frequency limited by TJ maximum VA = 1.5 x VR typical 2 A Document Number: 94308 Revision: 16-Mar-10 For te

M IFSM tp = 5 s sine VF 30 Apk, TJ = 125 C TJ Range UNITS A 35/45 V 1060 A 0.73 V - 65 to 150 C VOLTAGE RATINGS PARAMETER SYMBOL Maximum DC reverse voltage VR Maximum working peak reverse voltage VRWM VS-MBRB2535CTPbF VS-MBR2535CT-1PbF VS-MBRB2545CTPbF VS-MBR2545CT-1PbF UNITS 35 45 V ABSOLUTE MAXIMUM RATINGS PARAMETER Maximum average forward current SYMBOL per leg per device Peak repetitive forward current per leg Non-repetitive peak surge current TEST CONDITIONS TC = 130 C, rated VR IFRM Rated VR, square wave, 20 kHz, TC = 130 C IFSM UNITS 15 IF(AV) 5 s sine or 3 s rect. pulse VALUES 30 Following any rated load condition and with rated VRRM applied 30 1060 Surge applied at rated load conditions halfwave, single phase, 60 Hz 150 A Non-repetitive avalanche energy per leg EAS TJ = 25 C, IAS = 2 A, L = 8 mH 16 mJ Repetitive avalanche current per leg IAR Current decaying linearly to zero in 1 s Frequency limited by TJ maximum VA = 1.5 x VR typical 2 A Document Number: 94308 Revision: 16-Mar-10 For te

AND CHARACTERISTICS SYMBOL CHARACTERISTICS VALUES IF(AV) Rectangular waveform (per device) 30 IFRM TC = 130 C (per leg) 30 VRRM UNITS A 35/45 V IFSM tp = 5 s sine 1060 A VF 30 Apk, TJ = 125 C 0.73 V TJ Range - 65 to 150 C MBRB2535CT MBR2535CT-1 MBRB2545CT MBR2545CT-1 UNITS 35 45 V VOLTAGE RATINGS PARAMETER SYMBOL Maximum DC reverse voltage VR Maximum working peak reverse voltage VRWM ABSOLUTE MAXIMUM RATINGS PARAMETER Maximum average forward current SYMBOL per leg per device Peak repetitive forward current per leg TEST CONDITIONS Non-repetitive peak surge current Non-repetitive avalanche energy per leg Repetitive avalanche current per leg Document Number: 93979 Revision: 21-Aug-08 15 IF(AV) TC = 130 C, rated VR IFRM Rated VR, square wave, 20 kHz, TC = 130 C 5 s sine or 3 s rect. pulse IFSM VALUES UNITS 30 Following any rated load condition and with rated VRRM applied 30 1060 A Surge applied at rated load conditions halfwave, single phase, 60 Hz 150 EAS TJ = 25 C, IAS = 2 A, L = 8 mH 16 mJ IAR Cur
