e see www.vishay.com/doc?99912 TO-263 APPLICATIONS D * Power supplies: - Uninterruptible power supplies - AC/DC switch-mode power supplies - Lighting S Top View G * Synchronous rectification D G * DC/DC converter * Motor drive switch Ordering Information: SUM70060E-GE3 (lead (Pb)-free and halogen-free) S * DC/AC inverter * Battery management N-Channel MOSFET ABSOLUTE MAXIMUM RATINGS (TC = 25 C, unless otherwise noted) PARAMETER SYMBOL LIMIT Drain-Source Voltage VDS 100 Gate-Source Voltage VGS 20 Continuous Drain Current (TJ = 150 C) TC = 25 C TC = 125 C Pulsed Drain Current (t = 100 s) Avalanche Current Single Avalanche Energy a Maximum Power Dissipation a Operating Junction and Storage Temperature Range L = 0.1 mH TC = 25 C TC = 125 C ID V 131 75 IDM 240 IAS 50 EAS 125 PD UNIT 375 A mJ b 125 b W TJ, Tstg -55 to +175 C UNIT THERMAL RESISTANCE RATINGS PARAMETER SYMBOL LIMIT Junction-to-Ambient (PCB Mount) c RthJA 40 Junction-to-Case (Drain) RthJC 0.75 C/W Notes a. Duty cycle 1 %. b. See SOA curve
