TSSOP QFN PACKAGE MARKING 3.3 V 1.6 A TPS65100PWP TPS65100RGE TPS65100 3.3 V 1.6 A TPS65101PWP TPS65101RGE TPS65101 3.3 V 0.96 A TPS65105PWP TPS65105RGE TPS65105 The PWP and RGE packages are available taped and reeled. Add an R suffix to the device type (TPS65100PWPR) to order the device taped and reeled. The PWPR package has quantities of 2000 devices per reel, and the the RGER package has 3000 devices per reel. Without suffix the PWP package only, is shipped in tubes with 60 devices per tube. For the most current package and ordering information, see the Package Option Addendum at the end of this document, or see the TI Web site at www.ti.com. Submit Documentation Feedback TPS65100, TPS65101 TPS65105 www.ti.com SLVS496C - SEPTEMBER 2003 - REVISED APRIL 2006 ABSOLUTE MAXIMUM RATINGS over operating free-air temperature range (unless otherwise noted) (1) UNIT Voltages on pin VIN (2) -0.3 V to 6 V (2) -0.3 V to 15.5 V ENR (2) -0.3 V to VI + 0.3 V Voltages on pin VO1, SUP, PG Voltages on pin EN, MO

vice Status (1) Package Type Package Pins Package Drawing Qty Eco Plan Lead/Ball Finish MSL Peak Temp (2) (6) (3) Op Temp (C) Device Marking (4/5) TPS65100PWP ACTIVE HTSSOP PWP 24 60 Green (RoHS & no Sb/Br) CU NIPDAU Level-2-260C-1 YEAR -40 to 85 TPS65100 TPS65100PWPR ACTIVE HTSSOP PWP 24 2000 Green (RoHS & no Sb/Br) CU NIPDAU Level-2-260C-1 YEAR -40 to 85 TPS65100 TPS65100RGER ACTIVE VQFN RGE 24 3000 Green (RoHS & no Sb/Br) CU NIPDAU Level-2-260C-1 YEAR -40 to 85 TPS 65100 TPS65101PWP ACTIVE HTSSOP PWP 24 60 Green (RoHS & no Sb/Br) CU NIPDAU Level-2-260C-1 YEAR -40 to 85 TPS65101 TPS65101PWPR ACTIVE HTSSOP PWP 24 2000 Green (RoHS & no Sb/Br) CU NIPDAU Level-2-260C-1 YEAR -40 to 85 TPS65101 TPS65101RGER ACTIVE VQFN RGE 24 3000 Green (RoHS & no Sb/Br) CU NIPDAU Level-2-260C-1 YEAR -40 to 85 TPS 65101 TPS65105PWP ACTIVE HTSSOP PWP 24 60 Green (RoHS & no Sb/Br) CU NIPDAU Level-2-260C-1 YEAR -40 to 85 TPS65105 TPS65105PWPR ACTIVE HTSSOP PWP 24 2000 Green (RoHS & no Sb/Br) CU NIPDAU Level-2-260C-1 YEA
