{"Terminal Finish":"NOT SPECIFIED","Inductance-Nom (L)":"0.2000 uH","Operating Temperature-Max":"125 Cel","Tolerance":"10 %","Status":"ACTIVE","Lead Free":"Yes","Test Frequency (at L-nom)":"0.1000 MHz","Operating Temperature-Min":"-40 Cel","Core Material":"FERRITE","Number of Functions":"1","Inductor Application":"POWER INDUCTOR","Shape/Size Description":"RECTANGULAR PACKAGE","DC Resistance":"5.00E-4 ohm","EU RoHS Compliant":"Yes","Terminal Placement":"DUAL ENDED","Terminal Shape":"WRAPAROUND","Manufacturer...

{"Category":"Inductors, Coils, Chokes","Current Rating":"49A","Operating Temperature":"-40\u00b0C ~ 125\u00b0C","Featured Product":"FP/HCP Series Inductors","Package / Case":"Nonstandard","Current - Saturation":"38A","Type":"Wirewound","Shielding":"Unshielded","DC Resistance (DCR)":"0.5 mOhm","Height - Seated (Max)":"0.276\" (7.00mm)","Tolerance":"\u00b110%","Datasheets":"FP0807 Series","Inductance":"200nH","Standard Package":"600","Size / Dimension":"0.299\" L x 0.291\" W (7.60mm x 7.40mm)","Frequency - Te...

{"Failure Rate":"Not Required","Packaging ":"Tape and Reel","Military Standard":"Not Required","Number of Terminals":"2","Product Height (mm)":"7(mm)","Rad Hardened":"No","DC Current":"45000(mA)","Test Frequency":"0.1(MHz)","Operating Temp Range":"-40C to 125C","Product Depth (mm)":"7.6(mm)","Product Diameter (mm)":"Not Required(mm)","Technology":"Wirewound","Tolerance (+ or -)":"10%","DC Resistance":"0.0005(TYP)(ohm)","Type":"Power","Product Length (mm)":"7.4(mm)","Core Material":"Ferrite"}...
