{"Terminal Finish":"NOT SPECIFIED","Inductance-Nom (L)":"0.0700 uH","Operating Temperature-Max":"125 Cel","Tolerance":"10 %","Status":"ACTIVE","Lead Free":"Yes","Test Frequency (at L-nom)":"0.1000 MHz","Operating Temperature-Min":"-40 Cel","Core Material":"FERRITE","Number of Functions":"1","Inductor Application":"POWER INDUCTOR","Shape/Size Description":"RECTANGULAR PACKAGE","DC Resistance":"2.90E-4 ohm","EU RoHS Compliant":"Yes","Terminal Placement":"DUAL ENDED","Terminal Shape":"WRAPAROUND","Manufacturer...

{"Category":"Inductors, Coils, Chokes","Current Rating":"55A","Tolerance":"\u00b110%","Operating Temperature":"-40\u00b0C ~ 125\u00b0C","Featured Product":"FP/HCP Series Inductors","Package / Case":"Nonstandard","Current - Saturation":"140A","Type":"Wirewound","Shielding":"Unshielded","DC Resistance (DCR)":"0.29 mOhm","Height - Seated (Max)":"0.295\" (7.50mm)","PCN Assembly/Origin":"Multiple Devices 31/Aug/2013 Coiltronics Magnetics Facility 31/Aug/2013","Datasheets":"FP1107 Series","Inductance":"70nH","Sta...

{"Failure Rate":"Not Required","Packaging ":"Tape and Reel","Military Standard":"Not Required","Technology":"Wirewound","Product Height (mm)":"7.5(mm)","Rad Hardened":"No","DC Current":"55000(mA)","Product Length (mm)":"11(mm)","Test Frequency":"0.1(MHz)","Operating Temp Range":"-40C to 125C","Product Depth (mm)":"7.2(mm)","Product Diameter (mm)":"Not Required(mm)","Core Material":"Ferrite","Inductance":"0.07(OCL)/0.05(uH)","Tolerance (+ or -)":"10%","Type":"Power","Number of Terminals":"2","DC Resistance":...
